EV platform

CMA

Compact Modular Architecture

Geboren als hybride-platform, doorontwikkeld tot volwaardige EV-basis. De XC40/C40 (nu EX40/EC40) en Polestar 2 tonen hoe een platform binnen zijn levensduur fundamenteel kan verbeteren: van voorwiel- naar achterwielaandrijving, met grote sprongen in bereik en laadsnelheid.

CMA is the EV platform of Geely Group, in production since 2020, with a 400V architecture. The CMA platform carries 3 models from 2 brands. The WLTP range of the current variants on CMA runs from 479 to 659 km.

BrandsVolvo · Polestar
Since2020
Architecture400V
ChemistryNMC li-ion
Wheelbase2,70 – 2,74 m
Model
Generation
Variant
Volvo EX40 · Single
Platform schematic Volvo EX40 Single: 70 kWh NMC battery pack, 400V, RWD, 1 motor (0 front / 1 rear).
NMC cellsLFP cellse-motor

Volvo EX40

Single2025+ · EX40· verified
Specifications Volvo EX40 — Single
Battery (gross)70 kWh NMC
Battery (usable)67 kWh
DrivetrainRWD
Power175 kW
Motors1× · 0 front / 1 rear
WLTP range479 km
Real range (estimate)±385 km
Max DC charging180 kW
10 → 80%±30 min

Charging speed per variant

peak DC charging power · 10 → 80%

Models on this platform

WLTPreal (estimate)

Platform evolution

  1. 2017
    CMA-debuut
    Als ICE/hybride-platform onder de XC40
  2. 2020
    Eerste BEV's
    78 kWh Twin AWD (149 kW DC) — XC40 P8 & Polestar 2
  3. 2021
    Instapvarianten
    69 kWh FWD (XC40) en 64 kWh FWD (Polestar 2)
  4. 2023
    FWD → RWD
    Nieuwe achtermotor: 69 kWh RWD + 82 kWh (207 kW DC)
  5. 2024
    EX40 / EC40
    Rebrand + Polestar 2 tot 659 km WLTP
  6. 2026
    70 kWh instap
    Nieuw instappakket met hogere laadpiek voor EX40, EC40 en Polestar 2

Frequently asked questions

Which models are built on the CMA platform?
The CMA platform carries Volvo EX40, Volvo EC40 and Polestar 2.
Which group owns the CMA platform and how long has it been in production?
The CMA platform was developed by Geely Group, has been in production since 2020 and runs at 400V.
Which variant on the CMA platform charges fastest?
The Volvo EX40 Single Extended charges on the CMA platform at a peak of 207 kW and goes from 10 to 80% in ±32 minutes.
What is the WLTP range on the CMA platform?
The verified variants on the CMA platform reach a WLTP range of 479 to 659 km.
